S-143 Bevel
Price: open
Built-to-order
Body Profile | Grand Auditorium with Contour |
---|---|
Cutaway | Venetian |
Top | Solid Englemann Spruce |
Top Brace Pattern | AXL-brace |
Back | Solid Quilted Maple |
Sides | Solid Quilted Maple |
Back Brace Pattern | X-brace |
Fingerboard | Ebony |
Nut Width | 45mm |
Neck | Curly Maple |
Head Inlay | None |
Tuners | GOTOH/SGS510Z-BL5 CK |
Position Inlays | Original Design |
Scale Length | 652mm |
Strings | Jim Dunlop/DAP1254 |
Nut | Bone |
Saddle | Bone |
Bridge Pins | Graph Tech/TUSQ |
Bridge | Ebony |
Finish | Gloss |
Color | Natural - NAT |
Case | Hard Case |
Dimensions

A : | Overall length | 1,030mm |
---|---|---|
B : | Length of body | 500mm |
C : | Maximum width across upper bout | 275mm |
D : | Maximum width across lower bout | 394mm |
E : | Depth of body, upper bout | 95mm |
F : | Depth of body, lower bout | 115mm |
G : | Minimum width between bout | 238mm |
Please note that all measurements are approximate and rounded tu the nearest half-centimatre.
